| Item |
PT-6515 |
| CPU |
Intel® Celeron 2.0GHz processor J1900 |
| Chipset |
Intel chipset |
| LCD |
15″ LCD, resolution 1024 x 768 LED backlight LCD |
| Touch |
Projected Capacitive Touch |
| Construction |
Plastic cover & metal heat sink bottom |
| Memory |
2G up to 8G (DDR3) |
| Ethernet |
Onbaord 10/100/1000 BASE-T Gigabit Ethernet |
| Storage |
Internal 2.5″ type SATA HDD (optional SATA SSD) |
| External I/O Interface |
4 * COM ports [COM1~4 on rear I/O (COM1~2 powered with |
| |
DC+0/5/12V, BIOS selection; COM3~4 by Jumper setting) |
| |
1 * DB-15 VGA port |
| |
1 * DB-25 for LPT port |
| |
1 * RJ11 port supports 2 cash drawer(DC+24V) |
| |
1 * RJ-45 LAN port with activity and link LEDs |
| |
4 * USB 2.0 |
| |
1 * PS2 Keyboard port |
| |
1 * DC +12V input power-jack for adapter |
| Printer |
Front paper out 80mm 180 DPI 180mm/s or Rear Paper out |
| |
80mm 203 DPI 250mm/s |
| MSR |
3 tracks magnetic reader |
| Optional |
Integrated Customer display 2 x 20 VFD or CD-70 |
| |
Dual Pole display |
| |
RFID |
| |
WLAN |
| Operation System |
POS Ready7, Windows 7, Windows 8.1 Industry Pro Retail,Windows 10 |
| |
Linux (Ubuntu) |
| Power Supply |
AC100~240V/DC12V,15A, 180W adapter |
| Operating Temp |
0°C ~ +40°C |
| Certification |
CE, FCC, LVD, VCCI, BSMI, 3C |
